Dorman® Aluminum Spacer Profile – Open Type – Bronze (SC15O)
Schuco Aluminum Spacer Profile – Open Type is a precision-engineered extruded aluminum profile designed for insulating glass unit (IGU) spacer systems. It is used in the assembly of spacer frames between glass panes in double and triple glazing applications. The open-channel design allows accurate integration within IGU spacer bar systems and ensures stable structural positioning during fabrication. Manufactured from high-quality 6000 series aluminum alloy, it delivers excellent strength, durability, and corrosion resistance. With high dimensional accuracy and compatibility with modern IGU production lines, this profile is widely used in architectural glazing, façades, windows, and industrial glass applications where reliable spacer performance is required.
Technical details
- Product TypeAluminum Spacer Profile
- BrandDorman®
- Product NameDorman® Aluminum Spacer Profile – Open Type
- ModelSC15O
- Material GradeAluminum Alloy 6000 Series
- Manufacturing ProcessAluminum Extrusion
- ApplicationInsulating Glass Unit (IGU) Manufacturing
- FunctionAluminum Spacer Bar Housing and Frame Assembly Component
- IndustryGlass Processing Industry
- Profile TypeOpen Type
- Profile DesignOpen Channel Profile
- ShapeExtruded Aluminum Section
- Structural FunctionSpacer Frame Support and Assembly
- Nominal Profile Width15 mm
- Overall Profile Height23 mm
- Internal Width9.8 mm
- Base Width9.4 mm
- Bottom Opening5 mm
- Wall Thickness1.1 mm
- Corner RadiusR0.55 mm
- Profile Angle36.24°
- Standard Length6 m
- Custom LengthAvailable Upon Request
- Surface ConditionMill Finish
- Surface TreatmentAnodizing, Powder Coating, Sandblasting, Electrophoresis – Optional
- ColorBronze
- Optional ColorsNatural Aluminum, Black, White, Champagne, Golden
- Dimensional AccuracyHigh Precision Extrusion
- Corrosion ResistanceExcellent
- Mechanical StrengthHigh
- Weather ResistanceExcellent
- UV ResistanceExcellent
- CompatibilityAluminum Spacer Bar Systems
- Assembly MethodManual and Automated IGU Production Lines
- Maintenance RequirementLow
- Service LifeLong-Term Industrial Use
- Country of OriginChina
Description
Dorman® Aluminum Spacer Profile – Open Type is a precision-extruded aluminum profile used in insulating glass (IGU) spacer systems. The open-profile design provides a receiving channel for the aluminum spacer bar assembly, allowing integration within the complete spacer framework during IGU fabrication. Manufactured from high-quality 6000 series aluminum alloy, the profile offers excellent dimensional accuracy, structural strength, and corrosion resistance. It is designed for use in double and triple glazing systems where reliable spacer positioning, assembly accuracy, and long-term durability are required.
Spec & Technical Data
Dorman® Aluminum Spacer Profile – Open Type is manufactured from high-grade 6000 series aluminum alloy using precision extrusion technology to ensure consistent profile geometry and high structural performance. Based on the SC150 drawing, the profile features a nominal width of 15 mm, an overall height of 23 mm, internal width of 9.8 mm, base width of 9.4 mm, bottom opening of 5 mm, wall thickness of 1.1 mm, corner radius of R0.55 mm, and a profile angle of 36.24°. The product is supplied in standard 6-meter lengths with optional custom cutting available. It is delivered in mill-finish condition with optional surface treatments including anodizing, powder coating, sandblasting, and electrophoresis. The profile offers excellent dimensional accuracy, corrosion resistance, mechanical strength, and weather durability, making it suitable for insulating glass unit (IGU) production lines and spacer frame assembly systems.
