Demista Heated Mirror Demister Pad 150 X 2210
Model Number:
7015L221
Fast-heating anti-fog pad for clear, condensation-free mirrors.
Technical details
- Approved toEN60335-1:2002+A1,A2,A11,A12,A13,A14,A15 and EN60335-2-30:2009+A11
- Power Rating200W/m2
- Standard Voltage230V
- Insulation Class2-double insulated
- Thickness1 mm
- IP Rating44
- Cable connector30 x 40 x 5mm
- Cable1m twin core 0.75mm2 oval
- Adhesiveacrylic
- MaterialDouble insulated multi-layer polyester/polyethylene
- Mirror temperatureApproximately 15oC above ambient room temp.
- Heating time3-5 Minutes depending on ambient room temperature
- Heat spreadApproximately 30% area around the pad
Description
High-performance anti-fog mirror heating pad designed to keep mirrors clear and condensation-free. Engineered with advanced double-insulated layers, it delivers fast heating, energy efficiency, and reliable performance in humid environments.
Spec & Technical Data
Demista? Model Number : 7015L221
Nominal Power (Watts): 57
Dimensions (mm): 150 X 2210
Resistance range (Ohms): 881 ? 1028
Current (Amps): 0.25
